Automation Direct DURApulse GS4 User Manual

Page 5–4
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 5: Serial Communications
GS4 Parameters Summary – Serial Communication Parameters (P9.xx) – (continued)
Parameter Range
Modbus Address Settings
Hex Dec Octal Default
P9.44
Comm Card Type
0: No Communication Card
1: reserved
2: reserved
3: reserved
4: MODBUS-TCP Slave
5: EtherNet/IP Slave
6: reserved
7: reserved
8: reserved
092C 42349 4454 0
P9.45
Comm Card Version 0~65535 092D 42350 4455 0
P9.46
Comm Card Production Code 0~65535 092E 42351 4456 0
P9.47
Comm Card Fault Code 0~65535 092F 42352 4457 0
P9.48
Comm Card IP Configuration
0: Static IP
1: Dynamic IP (DHCP)
0930 42353 4460 0
P9.49
Comm Card IP Address Octet 1 0~255 0931 42354 4461 0
P9.50
Comm Card IP Address Octet 2 0~255 0932 42355 4462 0
P9.51
Comm Card IP Address Octet 3 0~255 0933 42356 4463 0
P9.52
Comm Card IP Address Octet 4 0~255 0934 42357 4464 0
P9.53
Comm Card Mask Octet 1 0~255 0935 42358 4465 0
P9.54
Comm Card Mask Octet 2 0~255 0936 42359 4466 0
P9.55
Comm Card Mask Octet 3 0~255 0937 42360 4467 0
P9.56
Comm Card Mask Octet 4 0~255 0938 42361 4470 0
P9.57
Comm Card Gateway Octet 1 0~255 0939 42362 4471 0
P9.58
Comm Card Gateway Octet 2 0~255 093A 42363 4472 0
P9.59
Comm Card Gateway Octet 3 0~255 093B 42364 4473 0
P9.60
Comm Card Gateway Octet 4 0~255 093C 42365 4474 0
P9.61
reserved ~ 093D 42366 4475 0
P9.62
reserved ~ 093E 42367 4476 0
P9.63
Comm Card Factory Reset
0: No Action
1: Reset to the Factory Setting
093F 42368 4477 0
P9.64
Comm Card External Set
0, 2
Bit 0 = reserved
Bit 1 = Write Ethernet Parameters to
Comm Card
Bit 2 = reserved
0940 42369 4500 0
P9.65
reserved ~ 0941 42370 4501 0
P9.66
reserved ~ 0942 42371 4502 ~
P9.67
reserved ~ 0943 42372 4503 ~
P9.68
reserved ~ 0944 42373 4504 ~
P9.69~P9.84
Block Transfer Parameters; refer to separate “Block Transfer Parameters” summary table, page 5–5
P9.85
PLC Frequency Command Force
to 0
0~ 1h
Bit 0 = 1: Before PLC scan, set up PLC
Target Frequency = 0
0955 42390 4525 0
P9.86
COMM1 Protocol (via RS-485)
0: Modbus
1: BACnet
0956 42391 4526 0
P9.87
BACnet Address 0~127 0957 42392 4527 10
P9.88
BACnet Baud Rate 9�6~76�8 Kbps 0958 42393 4530 38�4
P9.89
BACnet Device Instance Low Word 0~65535 0959 42394 4531 10
P9.90
BACnet Device Instance High Byte 0~63 095A 42395 4532 0
P9.91
BACnet Max Polling Address 0~127 095B 42396 4533 127
P9.92
BACnet Password 0~65535 095C 42397 4534 0
