Chapter 1: Getting Started
Page 1–20
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
unpaCking frame size e drives
1)
Remove the 4 screws on the iron
plates. There are 4 iron plates and a
total of 16 screws.
2)
Remove the crate cover, packing filler,
and Quick-Start Guide.
3)
Remove the 8 screws that hold the
drive to the pallet.
4)
Lift the drive by hooking the lifting
eyes. The drive is now ready for
installation.
