Automation Direct DURApulse GS4 User Manual

Appendix F: PID Control
Page F–9
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
durapulse GS4 anD GS3 PiD Parameter ComPariSonS
DURAPuLSe GS4 & GS3 PID Parameter Comparisons – Summary
GS4 PID Parameter GS3 PID Parameter
P7.00
PID Action/Mode
P7.00
Input Terminal for PID Feedback
P7.01
reserved
P7.01
PV 100% Value
P7.02
PID Setpoint Source
(when PID enabled, this parameter data will be
mapped from P4.00~P4.01 dependent upon
whether in Remote=4.00 or Local=4.01)
P7.02
PID Setpoint Source
P7.03
PID Feedback Gain
P7.03
PID Feedback Gain
P7.04
PID Offset Value
P7.04
PID Setpoint Offset Polarity
P7.05
PID Setpoint Offset
n/a
n/a
P7.06
PID Setpoint Gain
P7.05
Keypad PID Setpoint
P7.10
Keypad PID Setpoint
P7.06
PID Multi-Setpoint 1
P7.11
PID Multi-setpoint 1
P7.07
PID Multi-Setpoint 2
P7.12
PID Multi-setpoint 2
P7.08
PID Multi-Setpoint 3
P7.13
PID Multi-setpoint 3
P7.09
PID Multi-Setpoint 4
P7.14
PID Multi-setpoint 4
P7.10
PID Multi-Setpoint 5
P7.15
PID Multi-setpoint 5
P7.11
PID Multi-Setpoint 6
P7.16
PID Multi-setpoint 6
P7.12
PID Multi-Setpoint 7
P7.17
PID Multi-setpoint 7
P7.13
Proportional Gain
P7.20
Proportional Control
P7.14
Integral Time
P7.21
Integral Control
P7.15
Derivative Value
P7.22
Derivative Control
P7.16
Upper Limit for Integral Time
P7.23
Upper Bound for Integral Control
P7.17
Derivative Filter Time Constant
P7.24
Derivative Filter Time Constant
P7.18
PID Output Frequency Limit
P7.25
PID Output Frequency Limit
P7.19
PID Feedback Value
n/a
n/a
P7.20
Feedback Signal Detection Time
P7.26
Feedback Signal Detection Time
P7.21
PID Feedback Loss
P7.27
PID Feedback Loss
P7.22
PID Feedback Loss Speed Level Default
P7.28
PID Feedback Loss Preset Speed
P7.23
reserved
n/a
n/a
P7.24
PID Offset Selection
P7.25
PID Mode Selection
P7.26
PID Reverse Enable
P7.27
Source of Sleep
P7.28
Integral Limit During Sleep
P7.29
Sleep Reference
P7.30
Wake-up Reference
P7.31
Sleep Time
P7.32
Wake-up Delay Time
P8.00
User Display (can be set to display PID values)
P8.00
User Defined Display Function
P8.01
Start-up Display Selection
n/a
n/a
P8.02
User Defined Format
P8.03
User Defined Max
P8.04
User Defined Setpoint
