Automation Direct DURApulse GS4 User Manual

Page F–10
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Appendix F: PID Control
GS4 ParameterS involveD in PiD Control – Summary
The following GS4 AC drive parameters are often involved in setting up PID control.
NOTE: The information provided herein is applicable only to the PID function. For fully detailed
parameter information and for the complete set of GS4 parameters, please refer to "Chapter 4: AC Drive
Parameters."
DURAPuLSe GS4 Parameters for PID Control – Summary
Parameter / Description
P3.03
Multi-Function Input (DI1)
P7.19
PID Feedback Value
P3.04
Multi-Function Input (DI2)
P7.20
Feedback Signal Detection Time
P3.05
Multi-Function Input (DI3)
P7.21
PID Feedback Loss
P3.06
Multi-Function Input (DI4)
P7.22
PID Feedback Loss Speed Level Default
P3.07
Multi-Function Input (DI5)
P7.23
reserved
P3.08
Multi-Function Input (DI6)
P7.24
PID Offset Selection
P3.09
Multi-Function Input (DI7)
P7.25
PID Mode Selection
P3.10
Multi-Function Input (DI8)
P7.26
PID Reverse Enable
P3.11
Multi-Function Input (option card DI10 or PLC X12)
P7.27
Source of Sleep
P3.12
Multi-Function Input (option card DI11 or PLC X13)
P7.28
Integral Limit During Sleep
P3.13
Multi-Function Input (option card DI12 or PLC X14)
P7.29
Sleep Reference
P3.14
Multi-Function Input (option card DI13 or PLC X15)
P7.30
Wake-up Reference
P3.15
Multi-Function Input (option card DI14 or PLC X16)
P7.31
Sleep Time
P3.16
Multi-Function Input (option card DI15 or PLC X17)
P7.32
Wake-up Delay Time
P3.17
Multi-Function Output Terminal 1 (Relay 1)
P8.00
User Display
P3.36
PID Deviation Level
n/a
P3.37
PID Deviation Time
P3.57
AUTO to HAND Switching Behavior
P4.00
1st Source of Frequency Command [Remote]
P4.01
2nd Source of Frequency Command [Local]
P4.02
Analog Input 1 (AI1) Function
P4.03
Analog Input 2 (AI2) Function
P4.04
Analog Input 3 (AI3) Function
P6.25
Upper Limit of Output Frequency
P6.26
Lower Limit of Output Frequency
P7.00
PID Action/Mode
P7.02
PID Setpoint Source
P7.03
PID Feedback Gain
P7.04
PID Offset Value
P7.05
Keypad PID Setpoint
P7.06
PID Multi-Setpoint 1
P7.07
PID Multi-Setpoint 2
P7.08
PID Multi-Setpoint 3
P7.09
PID Multi-Setpoint 4
P7.10
PID Multi-Setpoint 5
P7.11
PID Multi-Setpoint 6
P7.12
PID Multi-Setpoint 7
P7.13
Proportional Gain
P7.14
Integral Time
P7.15
Derivative Value
P7.16
Upper Limit for Integral Time
P7.17
Derivative Filter Time Constant
P7.18
PID Output Frequency Limit
