Automation Direct DURApulse GS4 - Page 66

Page 2–28
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 2: Installation and Wiring
main Terminal diagrams
frame size a main Terminals
-
DC-
2+
+1
B1 B2
R/L1 S/L2 T/L3 U/T1 V/T2 W/T3
POWER MOTOR
DC+
frame size b main Terminals
-
DC-
2+ +1
B1 B2
DC+
R/L1 S/L2 T/L3 U/T1 V/T2 W/T3
POWER MOTOR
frame size C main Terminals
-
DC-
2+ +1
B1 B2
DC+
R/L1 S/L2 T/L3 U/T1 V/T2 W/T3
POWER MOTOR
