Baumer VLXT - Linepwmduration; Linepwmdutycycle

111
V2.6 | 8/30/2022 | 1120758
Electricalspecications(OutputLine4...Line7)
Danger!
UseinwetenvironmentsrequiringIP67protection
Risk of electric shock. Electric shock can be fatal or cause serious injury.
Use is only permitted under consideration of pollution degree 2 and overvoltage
category 2.
The M12 connectors must comply with the IEC 61076-2-101 standard.
The dielectric strength and withstand voltage for the plug/socket combination must
be checked according to DIN EN 60664-1:2008-01 for 60 V.
U
EXT
: UL conform applications: 12 V (- 20 %) … 24 V (+ 20 %)
U
EXT
: not UL conform applications: 12 V (- 20 %) … 48 V (+ 10 %)
I
OUT
: - max. 1.5 A permanently in sum or per output individually
- Pulse 40 % of the period, max. 2.5 A (t
ON
max 1 s)
- t
ON
= < 0.2 μs / t
OFF
= < 0.2 μs
- max. Frequency: 500 kHz
Notice
In case of overload or short circuit, the outputs are disabled. To re-enable the output,
disconnect Power (IO) (pin 12) from the power supply or perform a DeviceReset.
7.10.7 LinePWMDuration
Sets the pulse time in μs, with which the illumination is pulsed.
Name LinePWMDuration
Category DigitalIOControl
Interface IInteger
Access Read / Write
Unit µs
Values 1 - 5000 (Increment: 1)
7.10.8 LinePWMDutyCycle
Sets the duty cycle (ratio of pulse duration to period time duration) in %. This value is
specied by the connected illumination.
Name LinePWMDutyCycle
Category DigitalIOControl
Interface IInteger
Access Read / Write
Unit %
Values 1 - 100 (Increment: 1)
