Add Defect Pixel to Defect Pixel List with Baumer Camera Explorer
Notice
The addition of defect pixels must be done in FullFrame (without Binning, without Width
/ Height / OffsetX / OffsetY), in raw data format and without activated color calculation.
1. Start the Camera Explorer. Connect to the camera. Select the prole GenICam
Guru if necessary..
2. Open the category LUT Control.
3. Locate an empty Defect Pixel List Index.
Defect Pixel List Entry PosX = 0
Defect Pixel List Entry PosY = 0
Avoid using existing coordinates!
4. Determine the coordinates of the defect pixel. Keep the mouse pointer over the
defect pixel. The coordinates of the defect pixel is displayed in the status bar.
For simplication, you can enlarge the image.
5. Enter the determined coordinates for X (Defect Pixel List Entry PosX) and Y
(Defect Pixel List Entry PosY).
6. Activate the registered Defect Pixel List Index (Defect Pixel List Entry Active =
True).
7. Stop the camera and start them again to take over the updated coordinates.
7.15.1 DefectPixelCorrection
Enable the correction of defect pixels.
Name DefectPixelCorrection
Category LUTControl
Interface IBoolean
Access Read / Write
Unit -
Values
true = 1 (On)
false = 0 (Off)
7.15.2 DefectPixelListEntryActive
Determines if the pixel correction is active for the selected entry.
Name DefectPixelListEntryActive
Category LUTControl
Interface IBoolean
Access Read / Write
Unit -
Values
true = 1 (On)
false = 0 (Off)
