Baumer VLXT - Regionselector (≥ Release 3 Only)

153
V2.6 | 8/30/2022 | 1120758
7.13.21 RegionSelector(≥Release3only)
Selects the Region of interest to control. The RegionSelector feature allows devices that
are able to extract multiple regions out of an image, to congure the features of those
individual regions independently.
Width
(Region 0)
Width
(Region 1)
=
Width
(Region 2)
=
Width
(Region 3)
=
Width
(Region 4)
=
(Example with 5 ROI's. Maximum 8 ROI's are possible.)
Name RegionSelector
Category ImageFormatControl
Interface IEnumeration
Access Read / Write
Unit -
Values
Region0 Selected feature will control the region 0.
Region1 Selected feature will control the region 1.
Region2 Selected feature will control the region 2.
Region3 Selected feature will control the region 3.
Region4 Selected feature will control the region 4.
Region5 Selected feature will control the region 5.
Region6 Selected feature will control the region 6.
Region7 Selected feature will control the region 7.
