7.7.14 TimerTriggerActivation
Selects the activation mode of the trigger to start the Timer.
Name TimerTriggerActivation
Category CounterAndTimerControl
Interface IEumeration
Access Read / Write
Unit -
Values
RisingEdge
Starts counting on the Rising Edge of the selected trig-
ger signal.
FallingEdge
Starts counting on the Falling Edge of the selected trig-
ger signal.
AnyEdge
Starts counting on the Falling or Rising Edge of the se-
lected trigger signal.
7.7.15 TimerTriggerSource
Selects the source of the trigger to start the Timer.
Name TimerTriggerSource
Category CounterAndTimerControl
Interface IEumeration
Access Read / Write
Unit -
Values
Action1 Starts with the assertion of the chosen action signal.
ExposureEnd Starts with the reception of the Exposure End.
ExposureStart Starts with the reception of the Exposure Start.
FrameTransfer-
Skipped
Frame Transfer Skipped.
Line0
Starts when the specided TimerTriggerActivation
condition is met on the chosen I/O Line.
Line1
Starts when the specied TimerTriggerActivation con-
dition is met on the chosen I/O Line.
Off Disables the Timer trigger.
Software Starts when the trigger was generated by the software.
TriggerSkipped Starts when a trigger was skipped.
