Baumer VLXT - Sensorwidth; Testpattern

156
V2.6 | 8/30/2022 | 1120758
7.13.29 SensorWidth
Effective width of the sensor in pixels.
Name SensorWidth
Category ImageFormatControl
Interface IInteger
Access Read only
Unit -
Values 0 ... 65535 (Increment: 1)
7.13.30 TestPattern
Selects the type of test pattern that is generated by the device as image source.
Name TestPattern
Category ImageFormatControl
Interface IEnumeration
Access Read / Write
Unit -
Values see table below
The following values are possible:
GreyDiagonalRamp GreyVerticalRampHorizontalAndVertical-
LineMoving
GreyDiagonalRampHorizontalAndVertical-
LineMoving
GreyVerticalRampHorizontalLineMoving
GreyDiagonalRampHorizontalLineMoving GreyVerticalRampVerticalLineMoving
GreyDiagonalRampVerticalLineMoving HorizontalAndVerticalLineMoving
GreyHorizontalRamp HorizontalLineMoving
GreyHorizontalRampHorizontalAndVerti-
calLineMoving:
Off
GreyHorizontalRampHorizontalLineMov-
ing
PseudonoiseAndStaticRegions (.JP only)
AVAILABLE: (TestPatternGeneratorSelec-
tor = ImageProcessor).
GreyHorizontalRampVerticalLineMoving VerticalLineMoving
GreyVerticalRamp
