7.7.5 CounterResetActivation
Selects the Activation mode of the Counter Reset Source signal.
Name CounterResetActivation
Category CounterAndTimerControl
Interface IEumeration
Access Read / Write
Unit -
Values
RisingEdge Resets the counter on the Rising Edge of the signal.
FallingEdge Resets the counter on the Falling Edge of the signal.
AnyEdge
Resets the counter on the Falling or rising Edge of the
selected signal.
7.7.6 CounterResetSource
Selects the signals that will be the source to reset the Counter.
Name CounterResetSource
Category CounterAndTimerControl
Interface IEumeration
Access Read / Write
Unit -
Values
Counter1End Resets with the reception of the Counter End.
Counter2End Resets with the reception of the Counter End.
Line0 (≥ Rel. 2 only) Resets by the chosen I/O Line.
Line1 (≥ Rel. 2 only) Resets by the chosen I/O Line.
Off Disable the Counter Reset trigger.
7.7.7 CounterSelector
Selects which Counter to congure.
Name CounterSelector
Category CounterAndTimerControl
Interface IEumeration
Access Read / Write
Unit -
Values
Counter1 Selects the counter 1.
Counter2 Selects the counter 2.
