Baumer VLXT - Hdrgainbrightarea; Hdrgaindarkarea

126
V2.6 | 8/30/2022 | 1120758
7.12.4 HDRGainBrightArea
Returns the sensor gain for bright areas of image. This value represents the lower gain
used as offset for the HDR image.
The following cameras support this function:
Camera Type HDRGainBrightArea
Mono
VLXT-06M.I ■
VLXT-17M.I ■
VLXT-28M.I ■
VLXT-55M.I ■
VLXT-71M.I ■
VLXT-81M.I ■
VLXT-126M.I ■
VLXT-240M.I ■
Name HDRGainBrightArea
Category HDRControl
Interface IFloat
Access Read only
Unit -
Values 1.000000 - 3.981072 (Increment: 0.10)
7.12.5 HDRGainDarkArea
Returns the sensor gain for dark areas of image. This value represents the higher gain,
which is derived from lower gain and HDRGainRatio.
The following cameras support this function:
Camera Type HDRGainDarkArea
Mono
VLXT-06M.I ■
VLXT-17M.I ■
VLXT-28M.I ■
VLXT-55M.I ■
VLXT-71M.I ■
VLXT-81M.I ■
VLXT-126M.I ■
VLXT-240M.I ■
Name HDRGainDarkArea
Category HDRControl
Interface IFloat
Access Read only
Unit -
Values 1.000000 - 3.981072 (Increment: 0.10)
