7.12.8 HDRGainRatioSelector
Selects the gain ratio for HDR mode. The following cameras support this function:
Camera Type HDRGainRatioSelector
Mono
VLXT-06M.I ■
VLXT-17M.I ■
VLXT-28M.I ■
VLXT-55M.I ■
VLXT-71M.I ■
VLXT-81M.I ■
VLXT-126M.I ■
VLXT-240M.I ■
Notice
The camera must be stopped before this feature can be set.
Notice
You can use the HDRSplitviewEnable feature to display a before and after image of
your setting.
Name HDRGainRatioSelector
Category HDRControl
Interface IEnumeration
Access Read / Write
Unit -
Values
DynamicRange12_0dB
Sets HDR gain ratio to dynamic range of
12.0 dB. (Gain B 4 times higher than Gain A)
DynamicRange2_5dB
Sets HDR gain ratio to dynamic range of
2.5 dB. (Gain B 1.33 times higher than Gain A)
DynamicRange3_5dB
Sets HDR gain ratio to dynamic range of
3.5 dB. (Gain B 1.5 times higher than Gain A)
DynamicRange6_0dB
Sets HDR gain ratio to dynamic range of
6.0 dB. (Gain B 2 times higher than Gain A)
DynamicRange9_5dB
Sets HDR gain ratio to dynamic range of
9.5 dB. (Gain B 3 times higher than Gain A)
Off
Sets HDR gain ratio to dynamic range of 0dB.
(Gain B and Gain A the same)
7.12.9 HDRProcessingEnable
Enables the calculation of an interleaved HDR image of the sensor to an HDR image. If
this feature is disabled while HDR is enabled the interleaved HDR image of the sensor
will be output.
Name HDRProcessingEnable
Category HDRControl
Interface IBoolean
Access Read / Write
Unit -
Values
true = 1 (On)
false = 0 (Off)
