Baumer VLXT - Regionmode (≥ Release 3 Only)

152
V2.6 | 8/30/2022 | 1120758
Camera Type Mono8 Mono10 Mono12 Mono12p Bayer RG8 Bayer RG10 Bayer RG12 Bayer RG12p RGB8 BGR8 YCbCr_422_8
Color
VLXT-06C.I.JP ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
VLXT-31C.I.(.JP) ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
*
VLXT-50C(.I) (.FO) ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □
VLXT-55C.I ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □
VLXT-71C.I ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □
VLXT-81C.I ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □
VLXT-90C.I ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □
VLXT-123C.I ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □
VLXT-126C.I ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □
VLXT-240C.I ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □
VLXT-490C.I (.EF) ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □
VLXT-650C.I (.EF) ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ □
*)
.JP cameras only
Notice
At (.JP) cameras and ImageCompressionMode = JPEG, only the pixel formats Mono8
and YCbCr422_8 are available.
7.13.20 RegionMode(≥Release3only)
Controls if the selected Region of interest is active and streaming.
Notice
The settings (Height, Width, OffsetX, OffsetY) of the respective region must be correct
in order to be able to activate them.
Notice
With activated ImageCompression (ImageCompression = on) the use of Region-
Mode is not possible.
Name RegionMode
Category ImageFormatControl
Interface IEnumeration
Access Read / Write
Unit -
Values
On Enable the usage of the Region.
Off Disable the usage of the Region.
