VLXN
Camera Type
Temperatures for emergency shutdown
(at internal temperature sensor)
Monochrome
VLXN-650M.I.JP
69 °C (156.2 °F)
4.3 Mechanical Tests
except .EF cameras
Environmental
Testing
Standard Parameter
Vibration,
sinussodial
IEC 60068-2-6 Continuous
oscillation
10-2000 Hz
Amplitude un-
derneath cross-
over frequencies
0,75 mm
Acceleration 1 g
Test duration 150 min (axis)
450 min (total)
Vibration, broad
band
IEC 60068-2-64 Frequency
range
10-2000 Hz
Acceleration 10 g
Test duration 5 h (axis)
15 h (total)
Shock IEC 60068-2-27 Pulse time 11 ms / 6 ms
Acceleration 50 g / 100 g
Bump IEC60068-2-29 Pulse Time 2 ms
Acceleration 100 g
.EF cameras only
Environmental
Testing
Standard Parameter
Vibration, broad
band
IEC 60068-2-64 Frequency
range
5-150 Hz
Acceleration 0.5 g
Test duration 5 h (axis)
15 h (total)
Shock IEC 60068-2-27 Pulse time 30 ms
Acceleration 5 g
