7.7.2 CounterEventActivation
Selects the Activation mode Event Source signal.
Name CounterEventActivation
Category CounterAndTimerControl
Interface IEumeration
Access Read / Write
Unit -
Values
RisingEdge Counts on the Rising Edge of the signal.
FallingEdge Counts on the Falling Edge of the signal.
AnyEdge
Counts on the Falling or rising Edge of the selected sig-
nal.
7.7.3 CounterEventSource
Selects the signals that will be the source to increment the Counter.
Name CounterEventSource
Category CounterAndTimerControl
Interface IEumeration
Access Read / Write
Unit -
Values
Counter1End Counts the number of Counter End.
Counter2End Counts the number of Counter End.
ExposureActive Counts all Exposures.
FrameTransferSkipped Counts when a frame transfer skipped.
FrameTrigger Counts the number of Frame Start Trigger.
Line0 (≥ Rel. 2 only) Counts by the chosen I/O Line.
Line1 (≥ Rel. 2 only) Counts by the chosen I/O Line.
Off Disable the Counter Reset trigger.
TriggerSkipped Counts when a Trigger skipped.
7.7.4 CounterReset
Does a software reset of the selected Counter and starts it. The counter starts counting
events immediately after the reset unless a Counter trigger is active. CounterReset can
be used to reset the Counter independently from the CounterResetSource. To disable the
counter temporarily, set CounterEventSource to Off.
Notice
Note that the value of the Counter at time of reset is automatically latched and reected
in the CounterValueAtReset.
Name CounterReset
Category CounterAndTimerControl
Interface ICommand
Access Write only
Unit -
Values -
