In general, the transmission delay is calculated as:
∑
≥
−
+−+=
n
3n
)1nCamera(gEtransferGi)nCamera(osureexp)1Camera(readout)1Camera(osureexp)nCamera(onDelayTransmissi
ttttt
Therewith for the example, the transmission delays of camera 2 and 3 are calculated as
follows:
t
TransmissionDelay(Camera 2)
= t
exposure(Camera 1)
+ t
readout(Camera 1)
- t
exposure(Camera 2)
t
TransmissionDelay(Camera 3)
= t
exposure(Camera 1)
+ t
readout(Camera 1)
- t
exposure(Camera 3)
+ t
transfer10Gige(Camera 2)
Solving this equations leads to:
t
TransmissionDelay(Camera 2)
= 32 ms + 50 ms - 32 ms = 50 ms
t
TransmissionDelay(Camera 3)
= 32 ms + 50 ms - 32 ms + 2.6. ms = 52.6 ms
