V2.6 | 8/30/2022 | 1120758

Dimensions (M58-mount)

103,82±0,412,9

60 ±0,2

M58 x 0,75

temperature

measurement point

92,2 8,33

M3 x 5/710 x

Pixel 0,0

18,2

28,5 15,7
