Feature Description
Binning (subordinate features only together selectable)
BinningHorizontal Number of horizontal photo-sensitive cells to combine to-
gether.
BinningHorizontalMode Sets the mode to use to combine horizontal photo-sensi-
tive cells together when BinningHorizontal is used.
BinningSelector Selects which binning engine is controlled by the Binning-
Horizontal and BinningVertical features.
BinningVertical Number of vertical photo-sensitive cells to combine to-
gether.
BinningVerticalMode Sets the mode used to combine horizontal photo-sensi-
tive cells together when BinningVertical is used.
BlackLevel Returns the black level used to capture the image includ-
ed in the payload.
CounterValue (≥ Rel. 2 only) Returns the current value of the selected Counter.
DeviceTemperature Device temperature in degrees Celsius (C). It is measured
at the location selected by DeviceTemperatureSelector.
ExposureTime Returns the exposure time used to capture the image.
FrameID Returns the unique Identier of the frame (or image)
included in the payload.
Gain Returns the gain used to capture the image.
Height Returns the height of the image included in the payload.
Image Transmits the Image data in chunk block.
ImageControl (subordinate features only together selectable)
DefectPixelCorrection On/Off the correction of defect pixels.
FixedPatternNoise On/ Off the Fixed pattern noise correction.
ReverseX On/Off Flip horizontally the image sent by the device. The
Region of interest is applied after the ipping.
ReverseY On/Off Flip vertically the image sent by the device. The
Region of interest is applied after the ipping.
LineStatusAll Returns the current status of all available Line signals at
time of polling in a single biteld.
OffsetX Horizontal offset from the origin to the area of interest (in
pixels).
OffsetY Vertical offset from the origin to the area of interest
(in pixels).
PixelFormat Returns the pixel format of the image included in the pay-
load.
SequencerSetActive Returns the active sequencer set.
Timestamp Returns the Timestamp of the image included in the pay-
load at the time of the FrameStart internal event.
TriggerID (Rel. 2 only) Returns the Trigger ID and the Trigger Source.
The Trigger ID counts the incoming triggers of the signal
selected at TriggerSource. When the signal Action1 is se-
lected, the Request ID and the Source IP of the triggering
device are output.
TriggerControl (≥ Rel. 3)
(subordinate features only
together selectable)
Returns ActionRequestID, ActionSourceIP, Timestamp,
TriggerCounter and TriggerSource.
Width Returns the width of the image included in the payload.
