BMP
®
61 Label Printer
User’s Manual
6-13
110-Block, Bix Block Label Type
Figure 6-8. Sample seqeunce types
4. In the Sequence Type field, from the drop down list, select the Sequence Type
to use.
5. In the Start Value field (except when “None” is selected in the Sequence Type
field), enter the first number of the sequence.
6. In the # of Strips field, enter the number of strips (labels) to be created in the
block configuration chosen.
Note: If serializing the data, additional strips will continue the serialization from the
last number of the previous strip. Example: When requesting two strips of a 4-pair
configuration, the first strip will contain values 1-12, the second strip will contain
numbers 13-24.
7. When finished, select .
