Brother MFC-9330CDW Service Manual

2-62
Confidential
■ Error code 8A01
The registration rear sensor detected that the fed paper was larger or smaller than the
specified size in 2-sided printing.
<User Check>
- Use the Letter to Legal size paper.
■ Error code 8C00
No paper is in the manual feed slot when printing from the manual feed slot.
<User Check>
- Load paper to the manual feed slot.
Size Error 2-sided
Specify the correct paper
Step Cause Remedy
1 Registration rear actuator
catching on some position
Re-assemble the registration rear
actuator.
2 Registration rear sensor failure Replace the paper feed unit.
3 Main PCB failure Replace the main PCB ASSY.
Manual Feed
Load paper
Step Cause Remedy
1 Registration front/rear/manual
feed sensor PCB harness
connection failure
Check the registration front/rear/manual
feed sensor PCB harness connection and
reconnect it.
2 Manual feed actuator catching on
some position
Re-assemble the manual feed actuator.
3 Manual feed sensor failure Replace the paper feed unit.
4 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
