Brother MFC-9330CDW Service Manual

2-72
Confidential
■ Error code A200
During document scanning, the first side document scanning position sensor detected that the
document length was 90 cm or more.
<User Check>
- Use documents equal to or smaller than A4 size.
- Remove the jammed paper.
■ Error code A300
Though a document was fed and conveyed by the specified distance or longer, the first side
document scanning position sensor did not detect the passing of the paper.
<User Check>
- Remove the jammed paper.
■ Error code A400
The ADF cover sensor detected that the ADF cover was opened.
<User Check>
- Firmly close the ADF cover.
Document Jam
Clear the scanner jam, then press the Stop Key.
Step Cause Remedy
1 First side document scanning
position actuator catching on
some position
Re-assemble the first side document
scanning position actuator.
2 First side document scanning
position sensor failure
Replace the first side document scanning
position sensor PCB.
3 Main PCB failure Replace the main PCB ASSY.
Document Jam
Clear the scanner jam, then press the Stop Key.
Step Cause Remedy
1 Coming off of first side document
scanning position actuator.
Re-assemble the first side document
scanning position actuator.
2 First side document scanning
position sensor failure
Replace the first side document scanning
position sensor PCB.
3 Main PCB failure Replace the main PCB ASSY.
Cover is Open
Close the ADF Cover
Step Cause Remedy
1
Coming off of ADF cover actuator. Re-assemble the ADF cover actuator.
2 ADF cover/document detection
sensor PCB harness connection
failure
Check the ADF cover/document detection
sensor PCB harness connection and
reconnect it.
3 ADF cover sensor failure Replace the ADF cover/document
detection sensor PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
