Brother MFC-9330CDW Service Manual

2-73
Confidential
■ Error code A500
Upon scanning a fax, the first side CIS white or black calibration data was not within the
normal range.
Error code A600
Though a fax was scanned again after A500 error, the first side CIS white or black calibration
data was not within the normal range.
Error code A700
The ROM color parameter does not match the first side CIS or second side CIS.
■ Error code A800
When an image was scanned and processed, an error was detected in ROM color parameter.
Error code A900
When an image was scanned and processed, a scanning error occurred.
■ Error code AC00
Upon scanning a fax, the second side white or black calibration data was not within the normal
range.
Scan Unable A5
Remove the original document. Turn the power off, then on again
Scan Unable A6
See Troubleshooting and routine maintenance chapter in User's Guide.
Print Unable A7
Turn the power off and then back on again.
Step Cause Remedy
1 First side/second side CIS unit
calibration data error
Perform "Function code 55". (Refer to
"1.4.18 Acquisition of white level data and
setting of CIS scanning area" in Chapter 5.)
2 First side CIS unit failure Replace the first side CIS unit.
3 Second side CIS unit failure Replace the second side CIS unit.
4 Main PCB failure Replace the main PCB ASSY.
-
Scan Unable A9
Step Cause Remedy
1 First side/second side CIS unit
calibration data error
Perform "Function code 55". (Refer to
"1.4.18 Acquisition of white level data and
setting of CIS scanning area" in Chapter 5.)
2 First side CIS unit failure Replace the first side CIS unit.
3 Second side CIS unit failure Replace the second side CIS unit.
4 Main PCB failure Replace the main PCB ASSY.
Scan Unable AC
Remove the original document. Turn the power off, then on again
Step Cause Remedy
1 Second side CIS unit calibration
data error
Perform "Function code 55". (Refer to
"1.4.18 Acquisition of white level data and
setting of CIS scanning area" in Chapter 5.)
2 Second side CIS unit failure Replace the second side CIS unit.
3 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
