Brother MFC-9330CDW Service Manual

2-79
Confidential
■ Error code D800
An error occurred during touch panel initialization.
<User Check>
- Check whether an object is placed on the touch panel.
■ Error code D900
An error occurred during panel PCB initialization.
<User Check>
- Check whether an object is placed on the control panel.
■ Error code DA00
After the initialization of the panel PCB, no response was sent from the panel PCB for a period
of time.
Touchscreen initialization failed
Remove any material which is on the touchscreen.
Step Cause Remedy
1 Touch panel ASSY harness
connection failure
Check the touch panel ASSY harness
connection and reconnect it.
2 Touch panel ASSY failure Replace the touch panel ASSY.
3 Main PCB failure Replace the main PCB ASSY.
-
Step Cause Remedy
1 Panel PCB harness connection
failure
Check the panel PCB harness connection
and reconnect it.
2 Panel PCB failure Replace the panel cover ASSY.
3 Main PCB failure Replace the main PCB ASSY.
-
Step Cause Remedy
1 Panel PCB failure Replace the panel cover ASSY.
2 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
