3-154
Confidential
(8) Pull out the HVPS flat cable from the Hole of the Side frame R.
Fig. 3-224
Assembling Note:
Assembling the HVPS flat cable with its crease smoothed out.
Side frame R
Hole
HVPS flat cable
<Right side>
