Brother MFC-9330CDW Service Manual

5-30
Confidential
■ Switching Dither Pattern
<Function>
This function is to switch the dither pattern when printed letters and/or slanted lines are not
smooth, and thin lines are rough or uneven.
"*" is displayed at the end of the currently specified function in the LCD display.
<Operating procedure>
(1) Press the 4 and 5 keys in this order in the initial state of the maintenance mode.
"USBNo." is displayed on the LCD.
(2) Press the or key to display "PS.DitherType" and then press the Mono Start key.
(3) Press the or key to select "PS.DitherType=0" or "PS.DitherType=1".
(4) Press the Mono Start key. "Accepted" is displayed on the LCD, and the machine returns
to the initial state of the maintenance mode.
■ Switching of ON/OFF of DirectPrint Color mode-Improve Gray Color
<Function>
This function is to switch ON/OFF of the print control for the gray color when other colors are
slightly blended in the gray color or the gray color is uneven upon printing.
"*" is displayed at the end of the currently specified function in the LCD display.
<Operating procedure>
(1) Press the 4 and 5 keys in this order in the initial state of the maintenance mode.
"USBNo." is displayed on the LCD.
(2) Press the or key to display "DP.ImpGray" and then press the Mono Start key.
(3) Press the or key to select "DP.ImpGray=ON" or "DP.ImpGray=OFF".
(4) Press the Mono Start key. "Accepted" is displayed on the LCD, and the machine returns
to the initial state of the maintenance mode.
LCD Description
PS.DitherType=0 Dither Pattern 0 is selected.
(A dither pattern which improves roughness of letters and slanted lines)
(default)
PS.DitherType=1 Dither Pattern 1 is selected.
(A dither pattern which alleviates banding)
LCD Description
DP.ImpGray=ON DirectPrint Color mode - Improve Gray Color. (Print control for gray
color) ON (Improves the symptom that other colors are slightly
blended in the gray color.) (default)
DP.ImpGray=OFF DirectPrint Color mode - Improve Gray Color. (Print control for gray
color) OFF (Improves the unevenness of the gray color.)

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
