Brother MFC-9330CDW Service Manual

5-57
Confidential
1 Model name 23 Not necessary for maintenance work
(ADF sensor log 1 to 4)
2 Serial number
3 Model code 24 Not necessary for maintenance work
(ADF sensor log 5 to 8)
4 Country code
5 Switch checksum (factory use) 25 Not necessary for maintenance work
(ADF sensor log 9 to 12)
6 Main firmware version
7 Sub firmware version 26 Estimated remaining life of toner (Cyan)
8 Boot firmware version 27 Estimated remaining life of toner (Magenta)
9 Demo firmware version 28 Estimated remaining life of toner (Yellow)
10 Panel firmware version 29 Estimated remaining life of toner (Black)
11 Panel boot firmware version 30 Remaining life of drum unit (Cyan)
12 ROM CheckSum 31 Remaining life of drum unit (Magenta)
13 RTC check
*1
32 Remaining life of drum unit (Yellow)
14 RTC backup
*1
33 Remaining life of drum unit (Black)
15 Time before RTC backup
*1
34 Remaining life of PF kit 1
16 Time after RTC backup
*1
35 Remaining life of belt unit
17 USB ID code 36 Remaining life of fuser unit
18 RAM size 37 Total printed page
19 Function code 72 result/
Function code 55 result/
Wireless LAN country setting/
Wireless LAN output value/
WLAN Setup setup history/
Toner type CMYK (Current)/
Toner type CMYK (Previously used)
*2
38 Total copied pages
39 Total printed PC pages
40 Total printed list/fax pages
41 Accumulated average coverage
42 Average coverage (Current toner)
43 Average coverage (Previous used toner)
20 Main PCB inspection log/
High-voltage inspection log/
Number of electric discharge errors/
Number of fuser unit errors/
Process execution state
(Function code 1 to 64)
44 Drum page count/Rotations of the drum
45 Rotations of the developer roller
(Current toner/Previous used toner)
46 Total printed pages per paper tray/
Paper size/Paper type
21 Next Power On State/
Process execution state
(Function code 65 to 128)/
Process execution checksum
47 Total printed pages by each toner cartridge
(Current toner/Previous used toner)
48 Rotations of the developer roller used in
printing (Current toner/Previous used toner)
22
Number of color correction
(hexadecimal) that has been executed
(Auto registration/
Developing bias voltage correction/
Gamma correction/
Auto registration (user)/
Developing bias voltage correction
(user)/Gamma correction (user)/
Registration error/
Color calibration flag)
49 Total number of paper jams/Paper jams that
have occurred in each section in the machine
50 Machine error log/Total pages printed by the
time of error occurrence/Temperature and
humidity at the time of error occurrence
51 Number of times that consumables and
periodical replacement parts have been
replaced
*3
52 Total pages of scanning/
Document jams that have occurred in ADF
53 Communication error log

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
