Brother MFC-9330CDW Service Manual

5-58
Confidential
*1
RTC: Real Time Clock
*2
00: Starter toner cartridge, 01: Standard toner cartridge, 02: High yield toner cartridge
*3
For toner cartridges, the value in the parentheses ( ) shows the number of times that toner
manual reset is performed. The # sign indicates that the most recent new toner detection
was manual reset.
*4
The color toner value may become 0V when Function code 77 is executed.
*5
The maximum and minimum temperature and humidity is updated when the machine
comes out of the sleep mode.
54 Developing bias voltage value
*4
58 Temperature and humidity under which
Function code 77 is executed/Maximum
and minimum temperature and humidity
*5
55 Engine sensor log
(Not necessary for maintenance work)
56 Status log
(Not necessary for maintenance work)
59 Number of times that the power is turned
ON/Total power distribution time
57 Detailed code of machine error AF
(home position detection machine
error), detailed log of home position
detection machine error (16-byte
white tape data)
60 Date and time when the machine starts to
be used (Date and time when the first
printing is made with the driver)
61 Date and time when the machine starts to
be used (Initial set date and time of RTC)

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
