Brother MFC-9330CDW Service Manual

2-23
Confidential
D900 An error occurred during panel
PCB initialization.
2-79
DA00 After the initialization of the panel
PCB, no response was sent from
the panel PCB for a period of
time.
2-79
DB00 Communication between the
main PCB and panel PCB is
unavailable.
2-80
E000 Some ROM checksum error
occurred.
2-80
E100 Program error. 2-80
E400 ---
E500 Error occurred when DRAM on
the main PCB ASSY was
accessed.
2-81
E600 Error occurred during writing to
EEPROM on the main PCB
ASSY.
2-81
E700 ---
EC00 Overcurrent was caused
because a USB device that did
not meet the specifications was
inserted into the USB port.
2-81
F900 Setting by country code is not
entered.
2-81
FA01 ---
FA02 ---
FA03 ---
FB01 ---
FB02 ---
FB03 ---
FB04 ---
FB05 ---
FB06 ---
Error
codes
Problem
Refer
to:
FB07 ---
FB08 ---
FB09 ---
FB0A ---
FB0B ---
FB0C ---
FB0D ---
FB0E ---
FB0F ---
FC01 ---
FC02 ---
FC03 ---
FC04 ---
FC05 ---
Error
codes
Problem
Refer
to:

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
