Brother MFC-9330CDW Service Manual

2-46
Confidential
■ Error code 4C01
Dot counter of the toner cartridge (Black) or develop roller counter has reached the upper limit
was detected.
Error code 4C02
Dot counter of the toner cartridge (Yellow) or develop roller counter has reached the upper
limit was detected.
Error code 4C03
Dot counter of the toner cartridge (Magenta) or develop roller counter has reached the upper
limit was detected.
Error code 4C04
Dot counter of the toner cartridge (Cyan) or develop roller counter has reached the upper limit
was detected.
Error code 4C05
During printing, dot counter of color toner cartridge or develop roller counter has reached the
upper limit was detected.
<User Check>
- Replace the toner cartridge whose counter reached the upper limit.
Replace Toner
Open the Top Cover, replace Toner Cartridge.
Replace Toner
Open the Top Cover, replace Toner Cartridge.
Replace Toner
Open the Top Cover, replace Toner Cartridge.
Replace Toner
Open the Top Cover, replace Toner Cartridge.
Replace Toner
Open the Top Cover, replace Toner Cartridge.
Step Cause Remedy
1 Process drive unit damaged Replace the process drive unit.
2 Main PCB failure if the error code
remains after replacing with a
new toner cartridge and resetting
the toner counter
Replace the main PCB ASSY.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
