Brother PE-Design Next User Manual

239
Programmable Stitch Creator
Creating Motif Stitch Pattern
Step 3 Saving the created motif
stitch pattern
Motif stitch patterns are saved in the .pmf format.
Click 1, then 2.
Select the drive and the folder, and then type
in the file name.
 When saving a motif pattern, specify the
size beside Default Size. Click mm or
inch to select the measurement units.
Click Save.
Step 4 Using the edited motif stitch
pattern in Layout & Editing
Start up Layout & Editing.
Select an embroidery pattern.
From the Line sew type selector (in the
Attributes tab), select Motif Stitch.
Display the Sewing Attributes tab.
c
“Specifying sewing attributes” on page 58
Click below Motif in the Line sew section.
Select the drive and folder where the pattern
was saved in Step 3.
Click the created motif stitch pattern, and then
click OK.
 The pattern is applied to the outlines of
the embroidery pattern.
1
1
2
2
3
1
2
3
4
b Memo:
A motif stitch pattern can be used when the
motif stitch, piping stitch or stippling stitch has
been selected as the sew type of a region.
5
6
7
XE8656-001.book Page 239 Monday, May 24, 2010 5:44 PM
