L-TRX/L-19F
114 / 234 H172203_1_001
Diagnostic Functions
The numbers and types of the diagnostic functions, measurements and self-tests may vary,
depending on hardware level (ECL) and/or firmware release.
Figure11.15: L-TRX Diagnostic Functions
1 Select selftest to be executed.
2 Selftest result summary, use ‚Details‘ to read the complete selftest result log.
3 Diagnostic ADC measurements.
4 Reference clock status.
5 Refresh (update) measurements.
