BSVT Introduction & Configurations
H172203_1_001 129 / 234
12.8.3 CryoProbes
Figure12.7: CryoProbe
The BVT connector at the Cryo Controller has 24V on the male pins. Do not plug in the VTA
connector while the Cryo Controller is on; there is risk of short-circuiting. Contact your local
Bruker office for assistance.
When operating a RT probe, the Z116923 BSMS/2 VTA CRP must not be disconnected from
the Cryo Platform.
With BSVT the VT adapter box Z13874 is obsolete and must not be connected to the system.
