VTA
190 / 234 H172203_1_001
16.4.2 Measurements Provided for Diagnostic
The VTA detects shorted or disconnected lines at sensor interface connectors.
The VTA sends periodically measurement data and status information to the BSVT control
software running on the ELCB board. In case of failure (e.g. missing status information) the
VTA will be re-booted (power cycle on the VTA‘s 5 V).
The software running on the ELCB may notify the user about abnormal events (failures,
status information). This information is sent via ethernet from the ELCB board to the
workstation.
16.4.3 Calibration
There are no calibration settings to store on the VTA.
16.4.4 Connectors and LED‘s
Figure16.3: Two Typical VT Adapters
