AV4 BSMS System
30 / 234 H172203_1_001
4.1.2 Software Control of AV4 BSMS
All subunits may be accessed by a Web-based service tool, making service handling easy
and comprehensive.
The ELCB has an automatic save configuration mechanism and stores all the parameters (e.
g. for Lock, Shim, Lift, HE-Level measurement) within its nonvolatile memory (NVM). To be
able to switch back to a known state, a saved configuration from the installation may be
restored later - this fail-safe configuration can be re-activated by any user.
All activities of the AV4 BSMS and the data exchange with the TopSpin application are
logged by the ELCB software. This information is accessible by the service tool and,
additionally, it is periodically transferred to the workstation to keep a detailed long-term
history for trouble shooting. It is configurable how detailed the activities are logged.
4.2 Rack Configurations
In the following sub chapters, there are the various standard configurations described in
detail. For a list of the part numbers of the electronics units, please refer to Replacement of
Parts [}215].
NOTICE
Units of previous BSMS generations that are not explicitly mentioned in this
manual are not compatible to the AV4 BSMS Chassis!
u VME based Devices and the old Lock RF Units L-TX and L-RX will be destroyed when
powered up in the AV4 BSMS Chassis.
u Examples of VME Devices: SLCB, SLCB/2, SLCB/3, PNK, BSMS 2HTX, GAB, SCB13.
AV4 Units shall only be used in the AVANCE NEO generation of NMR Spectrometers.
