VPSB-DC and VPSB-DC-E
176 / 234 H172203_1_001
Ready LED
This LED is lit as soon as the FPGA program is loaded and the sensor interfaces are active
Power LED
An active Power LED indicates that the VPSB-DC(-E) is correctly powered
VT PWR 1
This LED is lit whenever the output power on the connector VTA1 is enabled
VT PWR 2
This LED is lit whenever the output power on the connector VTA2 is enabled
VTA 1 LED
Whenever a VTA is connected to the connector labeled VTA 1 and initialized correctly, the
LED will be switched on
VTA 2 LED
Whenever a VTA or BSCU is connected to the connector labeled VTA 2 and initialized
correctly, the LED will be switched on
AUX 1 LED
Whenever a VTA is connected to the connector labeled AUX 1 and initialized correctly, the
LED will be switched on
AUX 2 LED
Whenever a VTA or BSCU is connected to the connector labeled AUX 2 and initialized
correctly, the LED will be switched on
Connectors
Label Description Note
VTA 1 For VTA adapters that are used for power
channels (e.g. probe heater, LN2 accessory)
VTA 1 will be mapped to regulator channel 1
in Topspin
a
VTA 2 VTA 2 will be mapped to regulator channel 2
in Topspin
AUX 1 For VTA adapters that do not require heater
power (e.g. BCU control)
AUX 1 will be mapped to auxiliary channel 1
in Topspin
b
AUX 2 AUX 2 will be mapped to auxiliary channel 2
in Topspin
a
If a 2nd VPSB-DC(-E) is in use then its VTA 1 will be mapped to regulator channel 3 and VTA 2 to
regulator channel 4 respectively.
b
If a 2nd VPSB-DC(-E) is in use then the device at AUX 1 will be mapped to auxiliary channel 3 and
AUX 2 to auxiliary channel 4 respectively.
Table15.8: VPSB-DC(-E) Front Panel Connectors
