BSVT Introduction & Configurations
124 / 234 H172203_1_001
Full electronic VT gas control
• VT gas flow up to 2000 l/h (min. 4 bar of dry air or N2 gas) with SPB (for SB systems)
3000 l/h with SPB-E (for WB systems).
• Fine VT gas flow steps.
• Extended monitoring and logging capabilities.
• VT flow meter with approx. +/-5% precision.
• VT gas pressure meter with approx. +/-5% precision.
Other
• Minimum Topspin 3.0 required.
• Additional VT interfaces might be required for software control of existing probes and
accessories.
Probe interfaces no longer supported
Part Number Description
W1100255 THERMOCOUPLE HR 500WB
W1100407 THERMOCOUPLE HR 600MHZ
W1100401 THERMOCOUPLE HR 200-500MHZ
W1100884 THERMOCOUPLE HR 750MHZ
W1100024 HEATER SC FOR HP CXP/MSL
W1100316 HEATER SC ALL HR HEAD
W1100399 HEATER SC ALL HR HEAD
Table12.1: External Probe Interfaces no Longer Supported (discontinued products)
12.5 Basic BSVT Configuration
The basic BSVT configuration includes sample transport and rotation and cryostat helium
level measurement but does not include a VT system.
Part name Part Number ECL
AV4 BSMS Chassis
including power supplies
and fan tray
various
Bsms/2 ELCB Extended
Lock Cotrol Board
Z100818 >= 07.00
PNM Air Filter System
AVANCE Cabinet
88437 -
Table12.2: Minimal Requirements for all Configurations
