VPSB-DC and VPSB-DC-E
H172203_1_001 177 / 234
15.5 Service
A connected VPSB-DC(-E) in a BSMS system is controlled by the ELCB software - both the
specific low level drivers and the overall control logic are implemented there. The ELCB
software provides the operational functions for the NMR application by a CORBA interface. In
addition, there is a Web access available for service purpose (setup, calibration and
diagnostic). Some of these Web functions are open to all users (e. g. clients), other functions
are reserved for service engineers - it is necessary to log in and enter the required password
before these functions can be accessed (description in the BSMS Service Web [} 34]
chapter).
15.5.1 VPSB-DC(-E) Service Web
The VPSB-DC(-E) Service Page contains information about the board itself. Functions
controlled by the ELCB are described in the corresponding chapters.
Figure15.5: VPSB-DC Service Page
