Bruker NMR BSMS System - Technical Data for BSMS;2 Lock Transceiver (L-TRX)

L-TRX/L-19F
H172203_1_001 99 / 234
11.2.4 Technical Data BSMS/2 Lock Transceiver
Transmitter (TX):
Output power for gradient shimming @ +4 dBm input
power
Conditions: pulsed power only, max. pulse length = 1s,
max. duty-cycle = 10 %, all independent of actual output
power
min. 5 W
Output power for Lock operation:
FFA Mode (250µs pulse) typ. 28 dBm
Lock Mode (Lock pulse) -60...+20 dBm
Output power resolution typ. 0.1 dB
Frequency resolution ≤ 14 mHz
Phase resolution ≤ 0.1 °(deg)
Phase range 0..360 endless °(deg)
Frequency range f2H ± 1 MHz
Load mismatch:
no damage infinite VSWR
for on board diagnostics ≤ 3.6 VSWR
Confamp (except for Z109887 and Z109888 with ECL< 2) Supported
Receiver (RX):
Gain range 80 dB
Gain resolution 0.1 dB
