Bruker NMR BSMS System User Manual

BSVT Introduction & Configurations
H172203_1_001 135 / 234
12.11.2 BCU05 / BCU-X COOLING UNIT
Connection of BCU05 and BCU-X is identical using a Z116925 BSMS/2 VTA BCU.
Figure12.13: BCU05 or BCU-X Cooling Unit
Do not feed the heater power cable from the VTA thru the BSC-X. Connect the heater cable
directly to the probe.
