Bruker NMR BSMS System - BSVT and HT Solids Probe (High Temperature) Adaptation

BSVT Introduction & Configurations
132 / 234 H172203_1_001
12.9 BSVT and HT Solids Probe (High Temperature)
High Temperature Solids Probe
HT Solids Probe Heaters are directly connected to the VTA1 (Channel 1) of the VPSB-DC-E,
which provides up to 500 W of heater power. The BVTB3500 Booster option is no longer
required.
Figure12.10: VPSB-DC-E and solids Probe (up to 500W Heater Power)
The high power operation of VPSB-DC-E will also work with other probe adaptation like VTA
TC-T, VTA FLOW-NMR or VTA TC-2E etc. with appropriate ECL.
