Bruker NMR BSMS System - Technical Data for VTA TC-2 E; Technical Data for VTA LN2; Technical Data for VTA BCU

VTA
H172203_1_001 185 / 234
VTA TC-2E
Parameter Min Type Max Unit
Temperature measurement Range -200 +1000 °C
Thermocouple type E Accuracy (without
sensor)
+/- 1 °C
Number of channels 2
Connector type
a
B
Heater Connector type H
Maximum voltage 50 V
Maximum current 7 A
Safety temperature measurement Range -200 +850 °C
Thermocouple type K Resolution 0.1
Measurement update rate 1 s
-1
a
Connector types: See Figure 16.1 [}187]
Table16.7: VTA TC-2E
VTA LN2
Parameter Min Type Max Unit
Level measurement Range 0 500 ohm
Resistive PT100 type Resolution 0.1 ohm
Accuracy +/- 1 ohm
Stability °C/°C
Connector type
a
J
Heater Connector type J
Maximum voltage 50 V
Maximum current 7 A
Safety temperature measurement Range -200 +850 °C
Resistive PT100 type Resolution 0.1 °C
Measurement update rate 1 s
-1
a
Connector types: See Figure 16.1 [}187]
Table16.8: VTA LN2
VTA BCU
Parameter Min Typ
e
Max Unit
Control signal output Max. voltage 5 V
