Bruker NMR BSMS System - AV4 PSM-48 V Power Supply Module

Power Supply Modules
48 / 234 H172203_1_001
7.3 Unit Description
7.3.1 AV4 PSM-48V Power Supply Module
The AC-input connector is on the front panel, the DC-output connects to the backplane.
The supply status is indicated on the front panel.
The unit has no serviceable parts or fuses.
Figure7.3: AV4 PSM-48V Overview
