The TopSpin compliant software architecture enables a seamless integration and provides a
convenient user interface with common GUI elements. The new plug & play feature makes
the system to behave very smart.
Figure12.3: Example of the VT Panel within Topspin 4.0
12.4 BSVT Specifications
General
• Multi channel intelligent Ethernet based VT architecture (PnP).
• Up to 2 heater channels (additional 2 channels possible).
• Up to 2 sensor / cooling channels (additional 3 channels possible).
• Software controlled shim cooling.
• Software controlled flush gas operation (SPB-E version).
VT control electronics
• Temperature setting resolution of 0.1 °C (TopSpin).
• BTO-2000 equivalent temperature stability.
• Applicable temperature range (without cooling option, dew point <4 °C):
– Min. regulated temperature approx. +30 °C with 25 °C input gas temperature.
– Max. temperature depending on probe.
