Chassis (Mainframe)
40 / 234 H172203_1_001
Slot Slot
ID
SSRB
Address
I2C Bus
No.
H0
Curre
nt
Fused
24V
Secti
on
He
Sup
ply
H0
Supply
Typical Unit
Slot 21 21 21 2 AUX -
Slot 22 22 22 2 AUX -
Slot 23 23 23 2 AUX -
Slot 24 24 24 3 AUX AV4 PSM-B
Slot 25 25 - 7 AV4 PCTRL
Slot 26 - - 5 AV4 PSM-48V [2]
Slot 27 - - 4 AV4 PSM-48V [1]
Fan
Tray
- - 6 Fan Tray
Backpla
ne
- - 6 Bpl
Table5.1: Slot Functions
5.2.3 Part Numbers
Bruker Part No. Description
Z152144 AV4 BSMS CHASSIS
Table5.2: Part Numbers
5.2.4 Technical Data
Technical
Number of front slots 13 Slot
Number of rear slots: 5x standard PSM (48V/B/
PCTRL), 1x SPB, 4x VPSB
10 Slot
SSRB clock 10 MHz
Mechanical
Length 48.3 cm
Width – 19 inch 48.3 cm
Height 6 + 1 HU 31.1 cm
Weight 5 kg
