SPB
H172203_1_001 161 / 234
Figure14.6: Multifunction Flush Gas Output
CryoPlatform Emergency Lift Detection
For the CryoProbe Systems there is a Sample Safety Option available. This option runs
independently from the NMR console and guarantees sample tempering (in case of a power
failure) and emergency sample lift (in case of vacuum breakdown).
This additional emergency lift air must NOT be fed directly into the emergency lift input as
with the legacy PNK3S. Instead the emergency lift air must be carried through an external
throttle valve.
As before the amount of emergency lift air flow must be adjusted with this external throttle
valve. Please contact your local Bruker office for assistance.
14.6 Bus Interface
The communication with the ELCB runs exclusively over the User Bus.
14.7 Service
A connected SPB in a BSMS system is controlled by the ELCB software - both, the specific
low level drivers and the overall control logic is implemented there. The ELCB software
provides the operational functions for the NMR application by a CORBA interface. In addition,
there is a Web access available for service purpose (setup, calibration and diagnostic). Some
