25 Technical Data
25.1 General Information
Data Value Unit
Weight without subunits 5 kg
Weight with subunits 40 kg
Length 51,0 cm
Width 48,3 cm
Height 31,0 cm
Sound Pressure Level
a
, maximum 63 dBA
a
Measured stand-alone, outside of the cabinet. For SPL including the cabinet and
protection instructions see the applicable manuals.
Table25.1: Technical Data: General Information
25.2 Connection Values
The BSMS System for AVANCE NEO has no single power inlet with mains distribution within
the chassis. Each power supply module with mains input is connected individually to the PDU
(power distribution unit) of the cabinet. The connecting values are given per supply module.
Data Value Unit
Voltage range
a
208 - 230 Vac
Apparent power consumption, rated maximum 8 A
Circuit protection
b
10 Amps AC
Frequency 50/60 Hz
a
Not all units within the cabinet allow input voltages as low as 100 VAC.
Therefore, the usable PSM input range is smaller than on the rating plate of the
AC/DC supply.
b
Two not replaceable internal fuses (L+N) per AC/DC supply, two supplies per
PSM.
Table25.2: Electrical Connection Values: AV4 PSM-48V
Data Value Unit
Voltage 100 - 240 Vac
Apparent power consumption, rated maximum 4 A
Circuit protection
a
4 Amps AC
Frequency 47 - 63 Hz
a
Two replaceable fuses (L+N), time-lag T.
Table25.3: Electrical Connection Values: AV4 PSB-12V
