BSVT Introduction & Configurations
126 / 234 H172203_1_001
12.7 Required Cables for VT Options
Figure12.4: Cables for Basic AV4 BSMS Configuration with VT System Option
12.8 BSVT Probe Adaptation
The whole variety of probe temperature sensor interfaces and VT accessories can be
adapted with smart VT interfaces (BSMS/2 VTA).
For the different probe or VT accessory interfaces dedicated smart VT interfaces are
available, for details see the following pages.
By default, delivered systems with VT option includes one smart VT interface for up to 2
thermocouple type T sensors.
