BST ekr CON 100 - Line;Contrast Scan Error (Exclamation Mark); Line;Contrast Transition Not Detected; Line;Contrast Transition Outside Scanning Area

Troubleshooting
12
ekr CON 100 – Installation and Operating Manual 123/130
During line and contrast scanning using the CLSPro600 line and contrast sensor an
exclamation mark is displayed in front of the symbol for Sensor 3.
The printed line / contrast transition to be scanned
is not detected by the line and contrast sensor.
►
Check print for missing print.
►
Repeat the setup on sensor CLSPro600 (see the
separate operating instructions of the line and
contrast sensor).
The printed line / contrast transition to be scanned
is located outside the scanning area of the
CLSPro600 line and contrast sensor.
►
Correct the position of the CLSPro600 line and
contrast sensor across the web running direction.
►
Read the separate operating instructions of the
CLS Pro 600 line and contrast sensor (EDP no.
MD.323).
