9
Operation
74/130 ekr CON 100 – Installation and Operating Manual
9 Operation
9.1 Safety Instructions
WARNING
Severe injuries and material damage due to faulty operation!
►
Ensure that operating is carried out by qualified and adequately
instructed personnel only.
9.2 Control Panel
Fig.31: Control panel
On the control panel you will find all control and display elements
that you need for the operation of the web guiding system.
Signals that are located on the remote control inputs of
the controller block the keys on the control panel with
counter functions.
You can find the function of the individual keys in the following
table.
